    Ubiquiti AFi-ALN-KIT Amplifi Alien WiFi 6 Mesh System Router
    Tri-Band Mesh System Router and MeshPoint

    Ubiquiti AFi-ALN-KIT Amplifi Alien Tri-Band WiFi 6 Scalable Mesh System Router and MeshPoint

    With the latest 802.11ax WiFi 6 technology, the Ubiquiti AmpliFi AFI-ALN-R delivers 4x overall network capacity and 2x coverage while reaching true gigabit speeds. It has a tri-band radio with 2.4 GHz and 5 GHz 802.11ax radios that are optimised for WiFi 6 performance while also being backwards compatible with earlier WiFi standards. To improve the performance of 5 GHz WiFi 5 devices, the third radio (4x4) can be enabled. You can use AmpliFi Alien as a standalone router or connect an unlimited number of AmpliFi Alien Routers as MeshPoints to enhance range coverage.

    Key Features

    • WiFi 6 performance
    • 5 GHz 8x8 Wi-Fi 6 radio (Max speed 4804 Mbps)
    • 2.4 GHz 4x4 Wi-Fi 6 radio (Max speed 1148 Mbps)
    • 5 GHz 4x4 Wi-Fi 5 radio (Max speed 1733 Mbps)
    • 4-Port Gigabit Ethernet switch
    • Scalable mesh system
    • True Gigabit Mesh
    • 8x8 super antenna system
    • 1 min setup
    • Intuitive 4.7" touch screen
    • Flexible interfaces
    • High-performance custom antenna array
    • 2.2 GHz 64-bit quad-core CPU
    • Expandable and powerful multi-radio mesh

    Intuitive Touchscreen

    The vibrant touchscreen displays network status and provides instant controls. For your convenience, set the display and the green LED ring automatically turns off.

    Flexible Interfaces

    The AmpliFi Alien router is a powerful and secure device with a single Gigabit internet port and an internal power source. Each Alien router has a 4 Gigabit Ethernet port LAN switch built in. Gigabit Ethernet may be installed in any room without the need of cables. For wireless communication, use WiFi 6, and for local wired connectivity, use the LAN ports.

    Performance

    AmpliFi Alien is designed to deliver the best possible performance to your home network, regardless of how many client devices are connected at the same time. Alien reduces dead spots and quadruples total home network capacity by utilising MU-MIMO and OFDMA for communication across twelve WiFi 6 5 GHz and 2.4 GHz Radios spatial streams. Alien also includes a dedicated 5 GHz radio with WiFi 5 (802.11ac) capabilities that you can use to dedicate bandwidth to performance-critical devices instead of competing with other devices on your home network.

    APP

    With the accompanying AmpliFi app, you can set up your AmpliFi network in under a minute. You can configure the AmpliFi Alien for your environment with user-friendly, yet feature-rich controls and statistics.

    Mesh System

    For the best performance in any room, place the AmpliFi Alien router in the centre of your home. To establish a mesh system and extend your signal around your home, add extra Alien routers.

    Ubiquiti AmpliFi AFI-ALN-R - Technical Specification

    Router Specifications

    • Dimensions: 110 x 110 x 250 mm (4.33 x 4.33 x 9.84")
    • Weight: 1.2 kg ( 2.65 lb)
    • Max. TX Power: 2.4 GHz: 23 dBm per chain, 5 GHz 19 dBm per chain (low band)/ 20 dBm per chain (high band)
    • MIMO: 2.4 GHz: 4x4 5 GHz: 4x4 (low-band) + 8x8 (high band)
    • Speed: 2.4 GHz: 1148 Mbps, 5 GHz: 1733 Mbps (low band)/ 4804 Mbps (high band)
    • Networking Interface: WiFi; Gigabit Ethernet: (1) WAN, (4) LAN
    • Max. Power Consumption: 35W
    • ESD/EMP Protection: ± 24kV Air/Contact
    • Buttons: Reset
    • Antennas: (1) Internal Dual-Band Metal Stamp with 12 Polarity
    • Display: 110.38 mm (4.7") Diagonal, 274 x 1268, 279 ppi, G+F Touch, Full Colour
    • WiFi Standards: Up to WiFi 6
    • Power Save: Supported
    • Wireless Security: WPA2
    • Operating Temperature: 14 to 113° F (-10 to 45° C)
    • Operating Humidity: 5 to 95% Noncondensing
    • Certifications: FCC / IC

    Max. Supported Data Rates

    • 802.11a: 54 Mbps
    • 802.11b: 11 Mbps
    • 802.11g: 54 Mbps
    • 802.11n: 600 Mbps + 600 Mbps
    • 802.11ac: 1733 Mbps + 3466 Mbps
    • 802.11ax (Available to Clients): 1148 Mbps + 4804 Mbps

    Mesh System Specifications

    • Dimensions: 110 x 110 x 250 mm (4.33 x 4.33 x 9.84")
    • Max. TX Power: 2.4 GHz: 23 dBm per chain, 5 GHz 19 dBm per chain (low band)/ 20 dBm per chain (high band)
    • MIMO: 2.4 GHz: 4x4 5 GHz: 4x4 (low-band) + 8x8 (high band)
    • Speed: 2.4 GHz: 1150 Mbps, 5 GHz: 1700 Mbps (low band)/ 4800 Mbps (high band)
    • ESD/EMP Protection: ± 24kV Air/Contact
    • Buttons: Reset
    • Antennas: (1) Internal Dual-Band Metal Stamp with 12 Polarity
    • WiFi Standards: Up to WiFi 6
    • Power Save: Supported
    • Wireless Security: WPA2
    • Operating Temperature: 14 to 113° F (-10 to 45° C)
    • Operating Humidity: 5 to 95% Noncondensing
    • Certifications: FCC / IC

    Max. Supported Data Rates

    • 802.11a: 54 Mbps
    • 802.11b: 11 Mbps
    • 802.11g: 54 Mbps
    • 802.11n: 600 Mbps + 600 Mbps
    • 802.11ac: 1733 Mbps + 3466 Mbps
    • 802.11ax (Backbone): 1148 Mbps + 4804 Mbps
    • 802.11ax (Available to Clients): 1148 Mbps + 4804 Mbps





    Intuitive Touchscreen

    The vibrant touchscreen displays network status and provides instant controls.

    For your convenience, set the display and the green LED ring automatically turns off.

    • Resolution: 274 x 1268, 279 ppi

    • Full Colour

    • Size: 4.7 Inch (diagonal)

    • Controls: Touch Controls and Haptics
    Intuitive Touchscreen

    Flexible Interfaces

    Flexible Interfaces

    AmpliFi Alien is a powerful and secure router with a single Gigabit internet interface and internal power supply.

    Each Alien router has an integrated LAN switch with 4 Gigabit Ethernet ports.

    Bring Gigabit Ethernet into any room without pulling wires. Use Wi-Fi 6 for wireless connectivity and the LAN ports for local wired connectivity


    Performance

    AmpliFi Alien is optimised to provide your home network with the highest possible performance regardless of how many client devices are connected simultaneously. Utilising MU-MIMO and OFDMA for communication across twelve Wi-Fi 6 spatial streams, Alien eliminates dead spots and increases total home network capacity by four times. Alien also offers a separate 5 GHz radio with Wi-Fi 5 (802.11ac) speeds which you can dedicate to performance-critical devices and avoid competing for bandwidth with other devices on your home network.

    • Antenna: High-Performance Custom Antenna Array

    • Processor: 2.2 GHz 64-Bit Quad-Core CPU

    • Wi-Fi 5: 5 GHz Radio

    • Wi-Fi 6: 5 GHz and 2.4 GHz Radios

    AmpliFi App. Simple Setup, Rich Controls.

    Set up your AmpliFi network in a minute with the included AmpliFi app.

    User-friendly, yet feature-rich controls and statistics let you configure the AmpliFi Alien for your environment.

    • Always Know Who Is Using Your Network

    • Track ISP and System Performance

    • Guest Access, Simplified

    Scalable Mesh Wi-Fi Technology

    Simple and powerful Wi-FI 6 standard Mesh system that easily covers any home providing simultaneous 4K/8K UHD streaming and online gaming to multiple clients from any room.

    • 8x8 Wi-Fi 6 connection between Router and Mesh

    • True wireless gigabit speeds without noticeable latency between Router and Mesh point

    • No limitations to expand your network with additional AmpliFi Alien routers

    • Zero configuration efforts, fast installation and speed test from router screen

    • Gigabit LAN port located on dedicated MeshPoint for wired connection
