Technical Specification
General | |
Input voltage | 100 - 240 VAC |
Input frequency | 50/60 Hz |
Transfer Rate | up to 180MB/s |
Input current | 1.5 A |
Input connector | UK (Type G) |
Output voltage | 48 VDC |
Output current | 1.3 A |
Output connector | 2-PIN, with cord end terminals |
Weight | 353.5 g |
Additional | |
Input voltage absolute maximum | 90 - 264 VAC |
Input frequency absolute maximum | 47 - 63 Hz |
Maximum input inrush current | 50 A |
Output voltage absolute maximum | 45.6 - 50.4 VDC |
Short circuit protection | Yes |
HIPOT (dielectric withstand test) | Primary to Secondary: 4000 VDC |
MTBF | 50000 h |
Certification | Safety: EN 61558-1:2005/A1:2009, EN 61558-2-16:2009/A1:2013 (CB Scheme) EMC: EN 55032:2012+AC:2013, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015 |
