    StarTech PEX2PCIE4L PCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length

    PCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length

    Add two PCI and two PCI Express expansion card slots to your desktop computer






    The PEX2PCIE4L PCI/PCI Express Expansion Chassis provides a quick and simple I/O expansion solution to almost any PCI Express (PCIe) enabled system. Adding PCI/PCIe cards to a server or workstation, or providing a platform to swap cards between a mobile and desktop setup is a cost-effective and time-saving solution for maximizing the I/O capabilities of your system.


    The external expansion chassis adds two full-length (38cm) PCI slots (32-bit/33MHz), as well as two PCIe x1 (single-lane) slots to a host computer through a single PCI Express connection. Providing total bandwidth up to 250MBps from the PCIe x1 host controller card allows the computer to function as though the expansion chassis cards were connected directly to the motherboard.


    Backed by a StarTech.com 2-year warranty and free lifetime technical support.



    Applications:

    • Expand an existing systems PCI and PCI Express I/O capabilities
    • Add full-length or full-height cards to a small form factor system
    • Provide PCI support to systems with only PCIe slots
    • Ideal for system testers, and engineers who regularly swap out PCI or PCIe I/O cards


    Features:

    • Expansion bay providing 2 PCI ports (32-bit/33 MHz), and 2 PCIe single-lane ports (250MBps)
    • Self-powered PCI/PCIe expansion system with an on/off button
    • Rugged steel construction satisfies demands of industrial and server environments
    • Supports both 5V and 3.3V & 5V add-in PCI cards
    • Complies with PCI 2.3 and PCIe 1.1 specifications
    • Supports advance error reporting including ECRC support
    • Support add-in cards with extended length (38cm)


    The StarTech.com Advantage

    • Control the power state of connected PCI/PCIe cards with the self-powered chassis and easily accessible on/off button
    • Install additional cards without opening your computer with the provided external expansion card slots
    • Easy installation and support for small form-factor computers with an included low-profile/half-height bracket




    Ports & interfaces
    Hub interfaces PCI Express
    Ports quantity 4
    Cable length 0.9 m


    Features
    Certification ROHS, CE, FCC
    Cable length 0.9 m
    Data transfer rate 250 Mbit/s
    Housing material Steel


    Power
    Power plug type Type M
    Output voltage 12 V
    Output current 3 A
    Input voltage 115 - 230 V


    Operational conditions
    Operating temperature (T-T) 0 - 55 °C
    Storage temperature (T-T) -40 - 75 °C
    Operating relative humidity (H-H) 5 - 95 °C


    Weight & dimensions
    Width 137 mm
    Height 143 mm
    Depth 382 mm
    Weight 2 g

    Full specification and details can be found in the PDF file
