| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FEFAN7X15TX3 |
| Manufacturer No: | FAN7X15TX3 |
| Delivery: | In Stock: Next Day |
 |
70x15mm Replacement Ball Bearing Computer Case Fan w/ TX3 Connector
Add additional chassis cooling with a 70mm ball bearing fan
This versatile 70mm fan is an ideal replacement fan for keeping your computer running cool. The fan can be powered through a TX3 connection, and features a dual ball bearing design that ensures reliable cooling and longer fan lifespan.
The fan can be used to replace the fan component of some CPU coolers or mounted to the side panel of a computer case and features a tachometer pin on the TX3 motherboard connector that provides the host system with fan operating status information.
| Performance | |
| Rotational speed (max) | 3500 RPM |
| Noise level (high speed) | 34 dB |
| Type | Fan |
| Suitable for | Computer case |
| Operating temperature (T-T) | -10 - 70 °C |
| Fan diameter | 7 cm |
| Maximum airflow | 29.58 cfm |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 50000 h |
| Design | |
| Number of fans | 1 fan(s) |
| Material | Plastic |
| Product colour | Black |
| Certification | RoHS |
| Technical details | |
| Noise level (high speed) | 34 dB |
| Type | Fan |
| Suitable for | Computer case |
| Fan diameter | 7 cm |
| Maximum airflow | 29.58 cfm |
| Connector(s) | 1 - TX3 Female |
| Product life | 50000 h |
| Sustainability certificates | RoHS |
| Power | |
| Voltage | 12 V |
| Rated current | 0.18 A |
| Power consumption (typical) | 3.12 W |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 70 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 0 - 65% |
| Weight & dimensions | |
| Width | 15 mm |
| Height | 70 mm |
| Depth | 70 mm |
| Weight | 38 g |
| Other features | |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 0 - 65% |
| Rotational speed | 3500 RPM |
| Dimensions (WxDxH) | 10 x 60 x 60 mm |
| Connector(s) | 1 - TX3 Female |
| Product life | 50000 h |
Full specification and details can be found in the PDF file
