The Vision Rack VSR 800–1100VA UPS is a compact 1U rackmount line-interactive power protection system designed for servers, network infrastructure, and critical IT environments. With sinusoidal output, AVR stabilisation, and advanced connectivity options, it delivers high-efficiency protection while ensuring maximum uptime and reliable power continuity in rack-based deployments.
USB Interface
EnergyShare Socket
Plug & Play Installation
1U Rackmount Format
Datacentre / Server Use
Line Interactive Technology
SoHo / Small Office
Hot-Swap Battery System
Eco Energy Level 5
The Vision Rack UPS uses line-interactive technology combined with AVR and EMI filtering to stabilise incoming power. This reduces reliance on battery usage while maintaining high efficiency and ensuring continuous protection against mains disturbances.
When mains power fails, the inverter delivers a clean sinusoidal output to ensure compatibility with sensitive servers, networking hardware, and storage systems, maintaining stable and uninterrupted operation.
The EnergyShare socket enables intelligent load shedding, allowing non-essential devices to be disconnected during outages so that runtime is extended for critical infrastructure.
Front-access hot-swappable battery design allows for safe and simple replacement without shutting down connected equipment, ensuring continuous availability in critical rack environments.
The UPS supports USB and RS232 interfaces, expansion slots for interface boards, and compatibility with PowerShield3 software across multiple operating systems including Windows, Linux, VMware, and Unix-based platforms for full system visibility and control.
Designed for servers, storage, and network devices, the Vision Rack ensures high availability power protection with built-in safeguards including short circuit protection, auto restart, and emergency power off (EPO) support.
The Vision Rack range is designed to minimise energy consumption while maintaining high protection standards. With up to 98% efficiency and intelligent AVR-based operation, it reduces strain on power infrastructure while supporting long-term sustainability goals and reduced operational costs.
Built for modern IT environments, the system integrates seamlessly into 19” racks and supports critical uptime requirements through robust battery management, deep discharge protection, and continuous monitoring features.
Additional Features:
Superior protection
The Vision Rack range uses Line Interactive technology and provides a sinusoidal output voltage. This technology provides efficiency levels of 98% and therefore reduced energy consumption. It also ensures a high level of protection against mains power disturbances. The automatic voltage regulator (AVR) provides protection from surges, overvoltages and undervoltages, without battery intervention. Reduced battery usage ensures that the battery set is 100% available for mains power supply failures and is able to provide greater autonomy. EMI filters then provide further protection from voltage surges and transients. When the mains power supply fails, the load is powered by the inverter and receives a perfectly sinusoidal supply for maximum power continuity and reliability.
High availability
An EnergyShare socket allows loadshedding and the shutdown of less sensitive peripheral devices to extend battery runtime for critical loads. “Hot Swap” batteries can be removed via the front panel for easy and safe UPS maintenance. Battery test facility to detect deteriorating battery performance. Deep discharge protection to reduce battery ageing. Versatility Cold Start function to allow the UPS to power up with no mains power supply present. Display Vision models have a backlit LCD display providing UPS status information, load and battery performance.
Advanced communications
|
USB Plug |
|
Energy Share |
|
Plug & Play Installation |
|
Rack |
|
Datacentre |
|
Line Interactive |
|
SoHo |
|
Hot swap battery |
|
Eco Level 5 |
Riello UPS 's social commitment aims to help the present as well as shape a bright future, combining the inevitable need for energy with environmental protection.
Riello UPS uninterruptible power supplies power some of the most critical data centres and servers in use today. Within these environments, energy management is critical. Running costs must be minimised without compromising resilience, i.e. the ability to adapt to adverse external conditions whilst ensuring the complete availability of the services provided. Equipment must operate at the highest possible levels of efficiency to reduce the strain on critical power supplies and minimise the effect on the installation area.
Riello UPS models have always been compliant with the highest levels of efficiency in terms of energy protection and are classified according to a scale with 6 levels, corresponding with the efficiency value of the UPS with respect to the European Code of Conduct; this is known as the Eco Energy Level.
The Eco Energy Level system demonstrates how the most efficient UPS provide energy savings that allow the cost of their purchase to be recovered quickly compared to standard efficiency UPS , as well as how their use leads to significant reductions in carbon emissions into the atmosphere.
