PlenaFill Blanking Panels - Supplied in 27u Strips

PlenaFill® Blanking Panel Sheets

PlenaFill® blanking panels are supplied in 27U sheets and can be cut to any required size, avoiding the need to store several sizes of traditional blanking panel. PlenaFill® blanking panels are a proven solution to elimin ate hot spots and reduce overal cabinet temperatures.

The popular PlenaFill® Blanking Panel solution is now available in White as well as in the standard Dark Grey.

Air-intake temperature is known to be a significant factor in the reliability of IT equipment, with raised intake temperatures leading to equipment failure and expensive downtime. A major cause of raised air-intake temperatures is hot exhaust air recirculating through unsealed, open rack space.

Using blanking panels helps eliminate this issue. However, standard blanking panels have a horizontal gap between them that still allows hot exhaust air to leak into the front of the rack. PlenaFill® blanking panels are fixed in a sheet and eliminate this gap. Also by preventing the recirculation of hot exhaust air you’ll reduce bypass airflow and save on energy costs.

Features

• Pack of 10 PlenaFill® blanking panels equals 270 1.75" (44mm) rack mount "U's"
• Fits all 19" EIA server racks
• Sheets can be cut to fit any unused space, including less than 1U
• Fire rated material: ULVO class 94
• Quickly and easily fill large sections of un-occupied rack space, stopping bypass airflow
• No more guessing at how many blanking panels are needed
• Scalable, less storage space and less freight cost
• Installs in seconds – no tools required
• Fixings available for square hole, round hole and for 10/32 thread rails

Super inexpensive and highly efficient solution to optimise cooling and airflow in rack environments

Plenafill is a low-cost panel solution to securely seal the open U spaces in racks so that the hot air emitted by servers cannot recirculate back to the front of the rack. The keeps hotspots from forming on the racks and prevents the overheating, heat-related system malfunctions or even total failures. Plenafill thus plays an important role in optimising the use of cold air in the data centre and keeps the hardware at an ideal operating temperature.

Plenafill is an important component in green IT environments because it lowers your energy costs and extends the service life of your hardware – at minimal cost.

PlenaFill lowers temperature in data centres by up to 5.6 degrees Celsius

Another special advantage of Plenafill blanking panels is that they effectively separate the cold and warm air zones in rack environments which allows you to take full advantage of existing cooling capacities. Once Plenafill panels are installed, the output of your cooling systems can often be significantly lowered, thus reducing your energy costs considerably. According to Gartner, the air temperature can be lowered by an average of 5.6 degrees with blanking panels.

Specifications of the blanking panels for server cabinets

Plenafill is made of a solid yet lightweight plastic fire rated to UL94-V0. The solution can be easily attached in just a few minutes to the front of every 19" rack. You don’t need any tools, just special rivets that can be easily attached by hand. Every Plenafill sealing panel covers 27RUs in the rack. The perforated holes – which are, of course, air-tight – on every 1RU section let Plenafill panels be exactly adjusted to the size of the respective rack hardware equipment.

Plenafill highlights

• Prevents the recirculation of hot air
• Lowers bypass airflow in the rack
• Fire rated to ULV0 Class 94
• No tools necessary for installation
• Every blanking panel covers 27RUs of empty rack space – can be cut into 1RU sections
• Fits into all conventional 19” racks
• Extremely inexpensive and highly effective with a fast ROI
• Also ideal for optimising cold aisle containment – prevents warm air from recirculating back into the cold aisle

Benefits

Scalable panels significantly reduce time and labor cost associated with installation. No need to use separate filler panels for each rack manufacturer; works well in a multi-vendor environment. Rack units not lining up? PlenaFill can be cut to fill spaces less than 1 U and fits behind face plates.
