Maximum Performance and Security With Tri-Mode FunctionalityThe Adaptec® SmartRAID 3200 family is the industry's
most versatile, fully featured and secure full RAIDenabled Tri-Mode SAS/SATA/NVMe server storage
performance solution for server OEM, storage systems,
data center and enterprise customers.
The SmartRAID 3200 series of PCIe® Gen 4 to Tri-mode
RAID adapters come in a wide range of performance
optimized configurations optimized for the lowest
possible cost.
Built on Microchip's proven 5th generation storage controller, the SmartROC 3200, the SmartRAID 3200 product
supports both x8 and x16 PCIe Gen 4 host interface
adapters with 32, 16, and 8 media facing port variants for
both internal and external Tri-mode connectivity. The
SmartRAID 3200 Ultra products are specifically designed
for the most demanding NVMe and multi-port SAS SSD
applications. The SmartROC 3200 integrated PCIe Switch
enables DirectPath technology - the industry's lowest
latency and high
bandwidth NVMe solution and the flexibility to support x1, x2, x4, and x8 wide NVMe SSDs.
These industry first 24G SAS adapters support SAS-4
connectivity as well as Microchip's Dynamic Channel Multiplexing (DCM) technology that aggregates
expander attached SAS or SATA hard drives onto 24G
SAS infrastructure with near 100% link efficiency for
unparalleled throughput. Native host adapter modes,
RAID mode and mixed (RAID and HBA/raw devices) for
all media types are also supported.
Microchip’s Trusted Platform support delivers a new
level of compute and supply chain security based on
a hardware root of trust that is aligned with the Open
Compute Security Project. Microchip has expanded on
its unique maxCrypto™ Controller-Based Encryption
(CBE) solution to support SAS, SATA, and now NVMe
media.
Best-in-Class Ultra PerformanceThe SmartRAID 3200 series delivers a comprehensive feature
set for best-in-class performance. The distinctly labelled
SmartRAID Ultra adapters offer a x16 host interface that
doubles bandwidth to 29.6 GB/s, 4x the previous generation.
Non-ultra adapters still double bandwidth compared to
previous generations due to the Gen 4 PCIe interface. While
SmartRAID adapters commonly use 72-bit high-speed DDR4
3200 MHz, SmartRAID Ultra boards ship with either 144-bit
or 72-bit DDR4 3200 MHz memory, enabling the highest
throughput on redundant RAID writes and NVMe ControllerBased Encryption (CBE). The 144-bit boards are marked with
a "p" for performance (for example, SmartRAID 3258p-16i)
and support up to 11.7 GB/s throughput on RAID5 redundant
writes, which is 45% higher than 72-bit products and 17 GB/s
throughput on NVMe CBE-enabled LDs using maxCrypto™
Technology.
maxCrypto Controller-Based EncryptionThe SmartRAID encryption enabled adapters (denoted by /e)
provide the industry’s only data-at-rest CBE solution now enabled for NVMe in addition to SAS and SATA devices. maxCrypto technology encrypts data on RAID arrays and single-drive
RAID 0 with AES 256 encryption. It is accelerated by silicon
engines with all NVMe, SAS and SATA devices that are supported in RAID (SSDs and HDDs). It supports local encryption
key management and is FIPS 140-2/Level 1 certification ready,
providing a superior solution over self-encrypting drives
Advanced Data Protection and Ease of UseMicrochip's industry-leading smart storage stack delivers maximum reliability and best-in-class performance at all RAID levels,
plus unique features like mixed mode support (RAID and HBA devices can be used simultaneously), adapter power management
(reduces power consumption up to 30%) and Triple Mirroring features that allow data migration from existing RAID arrays to new
ones. SmartRAID 3200 series integrates Flash-based cache backup on most adapters to enable instant cache protection with an
onboard capacitor module (ASCM) on popular board variants. The Adaptec ASCM capacitor module supports a five-year lifetime
and is continuously monitored by the smart firmware to ensure a safe data backup to the onboard flash in case of a power loss.
All this is conveniently managed by the Adaptec maxView™ tools suite that includes arcconf
CLI, maxView HTML5-based web GUI,
and plug-ins for major storage management software suites for enterprise and data centers that allow remote and local management through standard desktops and mobile browsers
