| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | LIN32683 |
| Manufacturer No: | 32683 |
| Delivery: | In Stock: Next Day |
 |
The Lindy 32683 HDMI 4K60 Signal Generator & Display Emulator is a compact, professional?grade testing tool designed for AV installers, integrators, and technicians. Built to generate and emulate HDMI 18G signals, this portable device enables fast validation of HDMI sources, displays, and signal paths, making it ideal for troubleshooting, system commissioning, and on?site AV testing in both residential and commercial environments.
The Lindy 32683 functions as both an HDMI signal generator and a display emulator, allowing installers to either output a known test signal or emulate a connected display. This dual?mode functionality makes it an essential diagnostic tool for validating HDMI sources, cables, switchers, and displays during installation or fault?finding.
The device provides four pre?configured EDID resolutions, including 4K@60Hz 4:4:4, 4K@60Hz 4:2:0, 4K@30Hz 4:4:4, and 1080p@60Hz. Switching between EDID modes is simple and intuitive using the dedicated button on the side of the unit, enabling quick resolution testing without software.
When used as a display emulator, the unit detects HDCP content and HDMI signal status, including 5V and TMDS presence. Clear visual patterns indicate HDCP status, while LED indicators provide immediate feedback, helping installers quickly identify handshake or compatibility issues.
Designed for maximum convenience, the Lindy 32683 connects directly to HDMI sources or displays via integrated HDMI male connectors. No software installation or additional cables are required, making it a true plug?and?test solution for on?site work.
When operating as a display emulator, the unit is self?powered from the HDMI source. When used as a signal generator, it is powered via an external USB power supply. This flexibility ensures reliable operation in a wide range of testing scenarios.
With its extremely compact and lightweight design, the Lindy HDMI 4K60 Signal Generator & Display Emulator is easy to carry and store in any AV installer’s toolkit. It is perfectly suited for on?the?go professionals working on home installations, corporate meeting rooms, and large?scale AV deployments.
The Lindy 32683 HDMI 4K60 Signal Generator & Display Emulator is a compact, professional?grade testing tool designed for AV installers, integrators, and technicians. Built to generate and emulate HDMI 18G signals, this portable device enables fast validation of HDMI sources, displays, and signal paths, making it ideal for troubleshooting, system commissioning, and on?site AV testing in both residential and commercial environments.
The Lindy 32683 functions as both an HDMI signal generator and a display emulator, allowing installers to either output a known test signal or emulate a connected display. This dual?mode functionality makes it an essential diagnostic tool for validating HDMI sources, cables, switchers, and displays during installation or fault?finding.
The device provides four pre?configured EDID resolutions, including 4K@60Hz 4:4:4, 4K@60Hz 4:2:0, 4K@30Hz 4:4:4, and 1080p@60Hz. Switching between EDID modes is simple and intuitive using the dedicated button on the side of the unit, enabling quick resolution testing without software.
When used as a display emulator, the unit detects HDCP content and HDMI signal status, including 5V and TMDS presence. Clear visual patterns indicate HDCP status, while LED indicators provide immediate feedback, helping installers quickly identify handshake or compatibility issues.
Designed for maximum convenience, the Lindy 32683 connects directly to HDMI sources or displays via integrated HDMI male connectors. No software installation or additional cables are required, making it a true plug?and?test solution for on?site work.
When operating as a display emulator, the unit is self?powered from the HDMI source. When used as a signal generator, it is powered via an external USB power supply. This flexibility ensures reliable operation in a wide range of testing scenarios.
With its extremely compact and lightweight design, the Lindy HDMI 4K60 Signal Generator & Display Emulator is easy to carry and store in any AV installer’s toolkit. It is perfectly suited for on?the?go professionals working on home installations, corporate meeting rooms, and large?scale AV deployments.
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
