| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FEDIGI-USB2-4P |
| Manufacturer No: | DIGI-USB2-4P |
| Delivery: | In Stock: 2-3 Weeks |
 |
Intelix Series USB 2.0 High Speed High Performance Extension System w/ 4 Port USB hub on RX
USB2.0 High Speed extender over category cable extends USB2.0 signals up to 480Mbps up to 100m. 4 port hub on client side for multiple connected devices
The Intelix DIGI-USB2-4P extends computer USB 1.1 and USB 2.0 signals up to 100m (330 ft) over twisted pair cabling to four remote devices. The DIGI-USB2-4P utilizes inexpensive twisted pair cabling and has a throughput of up to 480Mbps. The DIGI-USB2-4P is perfect for keyboard and mouse extension, remote data ports, up to 4 USB hubs, security applications and interactive white board applications.
| Chassis and Environmental | |
| Enclosure | Black Anodized Aluminum |
| Dimensions | Local Extender: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0") Remote Extender: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0") |
| Operating Temperature | 0° to +50° C / +32° to +122° F |
| Operating Humidity | 20% to 80%, Non-condensing |
| Storage Temperature | -20° to +70° C (-4° to +158° F) |
| Storage Humidity | 10% to 90%, Non-condensing |
An owner's manual can be found in the PDF file
An installation guide can be found in the PDF file
Intelix Series USB 2.0 High Speed High Performance Extension System w/ 4 Port USB hub on RX
USB2.0 High Speed extender over category cable extends USB2.0 signals up to 480Mbps up to 100m. 4 port hub on client side for multiple connected devices
The Intelix DIGI-USB2-4P extends computer USB 1.1 and USB 2.0 signals up to 100m (330 ft) over twisted pair cabling to four remote devices. The DIGI-USB2-4P utilizes inexpensive twisted pair cabling and has a throughput of up to 480Mbps. The DIGI-USB2-4P is perfect for keyboard and mouse extension, remote data ports, up to 4 USB hubs, security applications and interactive white board applications.
| Chassis and Environmental | |
| Enclosure | Black Anodized Aluminum |
| Dimensions | Local Extender: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0") Remote Extender: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0") |
| Operating Temperature | 0° to +50° C / +32° to +122° F |
| Operating Humidity | 20% to 80%, Non-condensing |
| Storage Temperature | -20° to +70° C (-4° to +158° F) |
| Storage Humidity | 10% to 90%, Non-condensing |
An owner's manual can be found in the PDF file
An installation guide can be found in the PDF file
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
