| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | ENXN-ACPWR-715W-FB |
| Manufacturer No: | XN-ACPWR-715W-FB |
| Delivery: | In Stock: 7-10 Days |
 |
The 715 W AC PSU-FB (model XN-ACPWR-715W-FB with front-to-back ventilation airflow) works with all 5720 Series switch models.
The 715 W AC power supply has a keyed power inlet (C16) that requires a notched (C15) power cord.
The 715 W AC power supply has the status LEDs listed in the following table:
| IN_OK (Green) | OUT_OK (Green or Red) | Description |
|---|---|---|
| Off | Off | No AC input power connection or low AC voltage. |
| On | Off | AC input good, 54V output disabled. |
| On | (Red) On | AC input good, output (54V) fault. |
| On | (Green) On | AC input good. |
The 715 W AC PSU-FB (model XN-ACPWR-715W-FB with front-to-back ventilation airflow) works with all 5720 Series switch models.
The 715 W AC power supply has a keyed power inlet (C16) that requires a notched (C15) power cord.
The 715 W AC power supply has the status LEDs listed in the following table:
| IN_OK (Green) | OUT_OK (Green or Red) | Description |
|---|---|---|
| Off | Off | No AC input power connection or low AC voltage. |
| On | Off | AC input good, 54V output disabled. |
| On | (Red) On | AC input good, output (54V) fault. |
| On | (Green) On | AC input good. |
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
