The Cisco Meraki MS410 series extends cloud management across the aggregation layer for medium-size networks with our 1G fiber aggregation switches.
As with our access layer switches, our aggregation switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
To bring up a Meraki switch, simply plug it in. Meraki switches do not require CLI for switch configuration or port management.
Meraki’s centralized management gives administrators granular visibility into their network. Our dashboard helps you keep track of every configuration change in your network with our detailed event and change logs.
Aggregation switches to connect multiple access layer devices for a more versatile network
Available models with 16 or 32 x 1G SFP ports to support small- and medium-size enterprises 10G uplink interfaces on all models
Support for field replaceable, redundant power supplies
Up to 144G of switching capacity
6 configurable QoS queues for converged voice, video, and data applications
Integrated mounting brackets for rack mounting
Lifetime hardware warranty and advanced replacement at no additional cost
Industry-leading cloud management
Cloud management has a number of benefits that make it easier to build campus networks:
Automatic email alerts from power loss, downtime, excessive Layer 1 errors, or configuration changes
Powerful remote diagnostic tools such as packet capture to help isolate and troubleshoot network issues
Role-based administration
Firmware upgrades and enhancements from the Meraki cloud
Virtual Stacking enables switch port configuration changes on the dashboard interface without the need to physically stack switches
Incredible network transparency with application, operating system, client, and hostname visibility
Zero-touch provisioning for rapid deployment across sites
Specifications
Model | MS410-32-HW |
Physical Dimensions |
1.7 x 17.33" x 19.08" (4.37 x 48.46 x 51.66cm) |
Weight |
12.6 lbs (5.7 kg) |
Interface |
32 x 1G SFP fiber 4 x 10G SFP+ uplink 2 x stacking ports RJ45 Management port |
Switching capacity | 144 Gbps |
Stacking bandwidth | 160 Gbps |
