Axis 5503-161 THEIA LENS CS VARIF 1.8-3MM DC-IRIS

Axis 5503-161 THEIA LENS CS VARIF 1.8-3MM DC-IRIS

Barrel distortion corrected and IR corrected wideangle lens for cameras up to 5 mega pixel resolution. Compatible with e.g. M1114/-E, P1353/-E, P1354/-E, P1355/-E, P1357/-E, Q1602/-E, Q1604/-E, Q1614/-E, Q1615/-E.

by Axis
See more product details
Part No:FE5503-161
Manufacturer No:5503-161
Delivery: In Stock: 2-3 Weeks

/assets/images/gallery/large/16557165815503-161-1.png

Axis 5503-161 THEIA LENS CS VARIF 1.8-3MM DC-IRIS
More Related Items
Email product to a friend
X
  • Scroll to top
    Axis 5503-161 THEIA LENS CS VARIF 1.8-3MM DC-IRIS
    Barrel distortion corrected and IR corrected wideangle lens for cameras up to 5 mega pixel resolution. Compatible with e.g. M1114/-E, P1353/-E, P1354/-E, P1355/-E, P1357/-E, Q1602/-E, Q1604/-E, Q1614/-E, Q1615/-E.

    Theia Varifocal Ultra Wide Lens 1.8-3.0 mm

    Designed for ultra-wide field of view

    • Optical distortion correction by Theia’s Linear Optical Technology®

    • IR-corrected lens

    • F-number 1.5

    • Focal length 1.8–3 mm

    • Supports sensors up to 1/2.7"


    Theia Varifocal Ultra Wide Lens 1.8-3.0 mm lens incorporates patented Linear Optical Technology® which enables an ultra-wide field of view without barrel distortion. It is a varifocal lens, which lets you optimize the field of view from wide angle to ultra-wide. The rectilinear design of the lens enhances the resolution at the edges of the image, increasing the probability of detection.


    The lens is IR-corrected. This means that you don't need to adjust the camera's focus when you shift between day and night mode using the IR-cut filter.


    Theia Ultra Wide Lens 1.8-3.0 mm

    Camera Image sensor Angle of view
    AXIS P1375 1/2.8" 144°-86°
    AXIS P1375-E* 1/2.8" 133°-86°
    AXIS P1377 1/2.7" 110°-82°
    AXIS P1377-LE* 1/2.7" 110°-82°
    AXIS M1125/-E 1/3" 111°-85°
    AXIS P1354/-E 1/3" 105°-80°
    AXIS P1364/-E 1/3" 112°-84°
    AXIS P1365 Mk II 1/2.8" 114°-86°
    AXIS P1367 1/2.9" 108°-81°
    AXIS Q1615 Mk II 1/2.8" 115°-80°
    AXIS Q1615-E Mk II* 1/2.8" 89°-80°

    Compatibility

    The Theia Varifocal Ultra Wide Lens 1.8 – 3.0 mm with DC-iris is recommended for use with the AXIS P13 Series and AXIS Q16 Series. The lens is day/night corrected and therefore no adjustments will be needed when the IR-cut filter of the day/night camera disengages.

    Camera Image Sensor Angle of View*
    AXIS M1124/-E 1/2.8" 111°-85°
    AXIS M1125/-E 1/2.8" 111°-85°
    AXIS P1353/-E 1/3" 105°-80°
    AXIS P1354/-E 1/3" 105°-80°
    AXIS P1355/-E 1/2.8" 112°-84°
    AXIS P1357/-E 1/3.2" 102°-76°
    AXIS P1364/-E 1/3" 112°-84°
    AXIS P1365/-E 1/2.8" 112°-84°
    AXIS Q1602/-E 1/3" 105°-80°
    AXIS Q1604/-E 1/3" 106°-79°
    AXIS Q1614/-E 1/3" 105°-79°
    AXIS Q1615/-E 1/2.8" 112°-85°
    AXIS Q1615 Mk II 1/2.8" 115°-80°
    AXIS Q1615-E Mk II 1/2.8" 89°-80°

    * Angles achieved when the camera is used inside an Axis housing

    Compatible products

    AXIS M1124 AXIS P1346-E AXIS P1357 AXIS Q1602-E
    AXIS M1124-E AXIS P1347 AXIS P1357-E AXIS Q1604
    AXIS M1125 AXIS P1347-E AXIS P1364 AXIS Q1604-E
    AXIS P1343 AXIS P1353 AXIS P1364-E AXIS Q1614
    AXIS P1343-E AXIS P1354 AXIS P1365 Mk II AXIS Q1615
    AXIS P1344 AXIS P1354-E AXIS P1365-E AXIS Q1615 Mk II
    AXIS P1344-E AXIS P1355 AXIS P1365-E Mk II AXIS Q1615 -E
    AXIS P1346 AXIS P1355-E AXIS Q1602 AXIS Q1615 -E Mk II
