| Part No: | AHH8UK90/6C13/4C1916AWFC203B1 |
| Manufacturer No: | H8UK90/6C13/4C1916AWFC203B1 |
| Delivery: | In Stock: 7-10 Days |
 |
1-Phase Intelligent PDU Series
W Series 1-Phase intelligent PDUs can be integrated with your rack to provide power management, including monitoring of individual outlets or top-level circuits. Switched PDU models are also available that can provide remote on/off outlet switching functionality from anywhere in the world. Offered in many sizes and configurations, our smart PDUs provide the voltage, current, outlet number and type of connections required to fit any need.
Sophisticated W Meter with 2.8” LCD touchscreen
InfraPower® Intelligent PDUs are supplied with a sophisticated meter. The Single Phase W Meter not only provides local metering, but also daisy chain connection ports to connect up to 32 smart PDUs and 2 optional external sensors.
The 2.8" color LCD with touchscreen provides a sharp and highly visible display of kWh, kW, Power Factor, Volt, Amp, Temperature and Humidity. Apart from monitoring, W meter provides the cascade ports for daisy chain up to 32 x smart PDUs. For PDU IP access, simply connect one PDU IP Dongle for all daisy chain PDUs. This allows use of a single IP address throughout the power network.
The meter is hot swappable and field replaceable without needing to power down the PDU or attached mission critical equipment. Moreover, it provides real-time local & remote power monitoring with +/- 1% billing-grade accuracy.
With today’s increasing demand for high technology power management solutions, a complete smart rack PDU solution and the associated software allow data center managers to make key decisions regarding the most efficient use of power. The demand of 1-Phase intelligent PDUs with comprehensive features is increasing in data center field.
Key Features
Broadest Portfolio of 1-Phase
An extensive array of Intelligent Rack PDUs are available from stock with Custom rack PDU configurations to suit your exact requirements available at competitive prices and on short lead times. Austin Hughes build to order system enables us to produce and deliver quality solutions for your project.
High Metering Accuracy
InfraPower Intelligent PDUs provide real-time local & remote power monitoring with +/- 1% billing-grade accuracy. With reliable metering accuracy, data centers can produce industry grade billing for their co-location clients or for inter-departmental charging.
Quality PDUs in Short Lead Time
Austin Hughes designs highly reliable Single Phase PDUs using an efficient production, assembly and inventory process. Every InfraPower Rack PDU unit is 100% tested before shipment. All these efforts allow us to deliver quality PDUs to customers in the shortest lead time.
Slim Profile Design
For efficient rack mounting, InfraPower vertical PDU steel casing is designed with a slim profile starting from 54mm for a single IEC row. For most global branded IT racks this slim casing design allows dual PDU mounting to one side in the rack for single side power cabling orientation.
Circuit Protection
Safety operation is essential for your data center and server room. InfraPower Single Phase PDUs offer Resettable Fuse or Hydraulic MCB to protect the PDU circuit from current overload.
Compliance
Our dedicated PDU compliance team ensures conformance to safety and reliability standards in US, EMEA, APAC & ASEAN.
Free Management Software
The Free IPM-04 Windows based management software consolidates management of max. 800 1-Phase & 3-Phase PDUs via 50 IP dongles. 5 concurrent user access licences are part of the IPM-04 bundle, for achieving the demand of multi-user requirements in data center operations.
63A PDUs
In part due to the popularity of ultra-thin blade servers, sometimes a tremendous amount of computing power is required for equipment mounted in a single rack. W Series PDUs are designed for such high power usage requirements.
Inlet Options
IEC C20
16A Commando
32A Commando
| 1-Phase PDU Family | Intelligent | Metered | Basic | ||||
| Monitored | Switched | ||||||
| W | Wi | WS | WSi | MD | MK | ||
| Outlet Amp - kWh Measurement | • | • | |||||
| Outlet Switch ON / OFF | • | • | |||||
| Hot-Swap Meter | • | • | • | • | • | ||
| 1.8" Color LCD | • | • | • | • | • | ||
| Circuit Amp - kWh Measurement | • | • | • | • | • | ||
| Temp-Humid Sensor port x 2 | • | • | • | • | |||
| 16 PDU Levels in Single Daisy Chain | • | • | • | • | |||
| One IP Access up to 16 PDU Levels | • | • | • | • | |||
| SNMP Capability v2 / v3 | • | • | • | • | |||
| Free Management Software | • | • | • | • | |||
| Lockable IEC Outlet Model | • | • | • | • | • | • | • |
| Individually Fused Outlet Model | • | • | • | • | • | • | • |
| 63A Model (only for 230V PDU) | • | • | • | • | • | • | |
| Local Meter | • | • | • | • | • | • | |
| Tool-less Mounting for Vertical PDU | • | • | • | • | • | • | • |
| 0U / 1U / 2U Form Factors | • | • | • | • | • | • | • |
| Hydraulic MCB / Resettable Fuse Option | • | • | • | • | • | • | • |
| Voltage 230V / 208V / 110V | • | • | • | • | • | • | • |
| Operating temperature range -5°C to 60°C | • | • | • | • | • | • | • |
| Outlet types: IEC C13, IEC C19, IEC C13+C19, IEC Lockable, IEC Individually Fused, NEMA, UK, UK+IEC, SCH and SCH+IEC |
|||||||
