EPDU1016B Technical Specification | |||
Electrical | Nominal Voltage | 230VAC | |
Input Circuit | 16A | ||
Input Frequency | 50/60Hz | ||
Input Connector | IEC-320 C20 200-240V Inlet | ||
Input Cord Length | 2.5m | ||
Output Voltage | 200-240VAC, 1PH | ||
Output Receptacles | ( 8 ) C13 | ||
Circuit Breakers | N/A | ||
Physical | Mount Style | Horizontal (19" rack mountable) | |
Width | 488mm | ||
Height | 44.4mm | ||
Depth | 44.4mm | ||
Housing Material | Aluminum extrusion | ||
Tool-less Mounting | N/A | ||
Colour | Black | ||
Environmental | Operating Temperature | -5oC to +45oC | |
Operating Humidity | 5-95%RH, non-condensing | ||
Elevation Operating/Storage | 0–3000m / 0–15000m | ||
Regulatory | EMC | CE, followed by standard EN55035, EN55032, EN55024 | |
Safety | CE, TUV, followed by standard EN/IEC62368-1 | ||
Environment | RoHS, REACH | ||
Package | Rack Mounting Brackets | M6x16mm Screw (4pcs), M6 Cage Nut (4pcs) | |
Safety Sheet | Included | ||
Installations Instructions | Included | ||
Package Dimensions | 560*150*80mm | ||
Weight/Shipping Weight | 0.58KG/1.18KG | ||
Warranty | Length | 1 Year |
APC Easy Basic Rack PDUs provide reliable rack power distribution via a single input with multiple output receptacles and distribute power from low amperage single-phase circuits to higher-power 3-phase solutions.
