ExCam XPT Q6075 Explosion-Protected PTZ Camera
Zone-certified high-speed PTZ dome camera
• HDTV 1080p at 50/60 fps, with 40x optical zoom
• Axis Lightfinder 2.0
• Autotracking 2 and orientation aid
• TPM, FIPS 140-2 level 2 certified
• ATEX, IECEx, EAC and IA; Zone 1, 21
ExCam XPT Q6075 is a robust, high-performance PTZ camera that offers superior light-sensitivity for clear, sharp overview and excellent detail in near darkness. Enclosed in a stainless-steel housing, it's certified (ATEX, IECEx, EAC and IA) for use in potentially combustible environments. Featuring the new generation chip, it offers improved imaging, enhanced security features, extended capabilities for analytics and significantly more efficient video compression.
ExCam XPT Q6075 offers 40x optical zoom, superior video and excellent detail in HDTV 1080p resolution. Based on the new Axis chipset, it offers improved performance and features Axis Lightfinder 2.0 to capture images with more realistic and saturated colors and sharper images of moving objects. With focus recall there's no need to manually focus or wait the second or two it takes for autofocus to adjust. You get instantaneous focus even in challenging light conditions. Additionally, it includes autotracking 2 with click and track functionality for active object tracking, and orientation aid with support for dynamic overlays for quick orientation. Furthermore, Axis Zipstream with support for H.264/H.265 significantly lowers bandwidth and storage requirements.
This high-performance camera is packed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantee that the firmware hasn't been compromised and ensure only authorized firmware is installed. It also features a Trusted Platform Module (TPM, FIPS 140-2 level 2 certified) to ensure secure storage of all cryptographic keys and certificates. ExCam XPT Q6075 includes several Axis analytic applications that help keep personnel and equipment safe. Enter/exit detector can trigger an alarm if someone enters a restricted area, while guard tour can be used to monitor surrounding areas in case of remote installations, such as well heads. Plus, it's easy to add 3rd party analytics.
Significantly lighter than a traditional positioning camera, this PTZ dome camera weighs just 20 kg and comes enclosed in a robust, stainless steel explosion-protected housing. It's certified (ATEX, IECEx, EAC and IA) for use in potentially combustible environments. And, with IP66/IP68 ratings, you can rest assured that the camera housing is resistant to harsh weather conditions, dust and water. It's powered by Power over Ethernet (PoE) with just one ethernet cable for power and network access for quick and easy installation. Thus, the power source can be placed far from the camera to facilitate service and maintenance.
Capture color images in low-light conditions.
Make your network camera solution more intelligent with powerful analytics and functionality.
For intrusion detection
For detecting loiterers
Smart motion detection
| Performance | |
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| PTZ modes | Preset point |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Design | |
| Housing material | Stainless steel |
| Form factor | Bullet |
| Mounting type | Wall |
| Protection features | Corrosion resistant |
| IP Rating | IP66, IP68 |
| Camera | |
| Tilt angle range | 180 - 180° |
| Tilt speed | 450 °/sec |
| Pan range | 360 - 360° |
| Pan speed | 450 °/sec |
| Camera shutter speed | 1/11000 - 1/3 s |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| ogressive scan | Yes |
| Lens system | |
| Number of lenses | 1 |
| Zoom capability | Yes |
| Optical zoom | 40x |
| Digital zoom | 12x |
| Focal length range | 4.25 - 170 mm |
| Focus adjustment | 1.6 - 5.0 |
| Video | |
| Text caption overlay | Yes |
| Image stabilizer | Yes |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 320 x 180,1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Video intelligence analytic | Yes |
| Thermal frame rate (NTSC) | 50 - 60 Hz |
| Video recording | Yes |
| Storage | |
| Maximum memory card size | 128 GB |
| Card reader integrated | Yes |
| Built-in HDD | Yes |
| HDD capacity | 1 GB |
| Flash memory | 512 MB |
| Compatible memory cards | MicroSDXC |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 17.1 W |
| Power consumption (Power over Ethernet (PoE)) | 11 W |
| Power consumption (typical) | 11 W |
| Operational conditions | |
| Operating temperature (T-T) | -50 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100 % |
Full specification and details can be found in the Product Datasheet PDF file
