Deploy the UniFi UAP-XG Access Point in high-density environments requiring maximum wireless performance. The UniFi UAP-XG features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3bt PoE compatibility. Three client radios deliver unparalleled Wi-Fi performance while a dedicated security radio provides persistent threat management. The UniFi UAP-XG is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that may slow down a lesser-equipped AP. The primary port carries both data and PoE, while the secondary Gigabit Ethernet port is for bridging and also supports PoE input. Its sleek design seamlessly integrates into any environment and is compatible with existing UAP-AC-PRO mounts.
Key Features
WiFi speeds up to 4266 Mbps (800+1733+1733 Mbps)
Simultaneous Tri-Band 4x4 Multi-User MIMO.
Dedicated Security Radio with Persistent Threat Management.
Real-Time Spectrum and airTime Utilisation Engine.
Latest in Wi-Fi 802.11ac Wave 2 MU-MIMO technology combined with dedicated security and Bluetooth radios.
Includes Hotspot functionality:
Built-in support for billing integration using major credit cards.
Built-in support for voucher-based authentication, including the ability to generate voucher codes.
Built-in Hotspot Manager for voucher creation, guest management, and payment refunds.
Full customisation and branding of Hotspot portal pages, including use of your own logo.
The UniFi UAP-XG AP can be powered by any 802.3bt PoE compliant switch.
Four antennas with 2 x 2.4 GHzDual-Port 6dBi Dual-Polarity Antennas and 2 x 5GHz Dual-Port 8dBi Dual-Polarity Antennas.
Scalable Enterprise Wi-Fi Management
The UniFi® Ecosystem enables the system integrator to effectively and efficiently create wireless network designs of any size, from small to large, with the potential for unlimited scalability.The built-in, dedicated security and monitoring radio of the UniFi XG AP provides visibility into site performance, channel planning, and local interferers, allowing the integrator to properly evaluate performance and quickly respond to changing interference and security threat landscapes.
Easily accessible through any standard web browser and the UniFi mobile app (iOS or Android), the UniFi Controller software is a powerful software engine ideal for high-density client deployments requiring low latency and high uptime performance.Features:
Highlights:
Create a Future-Proof 10 Gigabit End-to-End UniFi Network
The Highest Performing WiFi AP in the World
High Density Tests conducted on Access Points where done in a high density environment with 100 WiFi clients running the test concurrently
Average Throughput Uplink (100 Clients) |
HD Video Streaming Average Multicast Pass Percentage(100 Clients) |
Average 5Mb FTP upload Time (100 Clients) |
Spectral Security
The UniFi WiFi AP delivers unprecedented wireless awareness and security, including tools for real-time spectrum monitoring, airtime utilisation analytics, and intrusion detection/prevention. Using a persistent spectral scan, the AP constantly monitors the RF environment to check for both potential malicious activity and the best channel for network performance.
Advanced Features in UniFi Controller
UniFi is the premiere Software Defined Networking (SDN) solution with seamless integration of high-performance switching, gateways, and more.
Access Point Comparison Chart
UAP-AC-IW | UAP-AC-LITE | UAP-AC-LR | UAP-AC-PRO | UAP-XG | UAP-AC-HD | |
Environment | Indoor | Indoor | Indoor | Indoor/ Outdoor | Indoor/ Outdoor (covered) | Indoor/Outdoor (covered) |
Simultaneous Dual-Band | ||||||
2.4 GHz Speed | 300 Mbps | 300 Mbps | 450 Mbps | 450 Mbps | 800 Mbps | 800 Mbps |
2.4 GHz MIMO | 2x2 | 2x2 | 3x3 | 3x3 | 4x4 | 4x4 |
5 GHz Speed | 867 Mbps | 867 Mbps | 867 Mbps | 1300 Mbps | (2) 1733 Mbps | 1733 Mbps |
5 GHz MIMO | 2x2 | 2x2 | 2x2 | 3x3 | (2) 4x4 | 4x4 |
Range | 122 mt | 183 mt | 122 mt | 122 mt | 122 mt | |
Secondary Ethernet Port | ||||||
PoE Mode | 802.3at PoE+ | 802.3af/A PoE 24V Passive PoE | 802.3af/A PoE 24V Passive PoE | 802.3af PoE 802.3at PoE+ | 802.3bt PoE | 802.3at PoE+ |
Ceiling Mount | ||||||
Wall Mount | ||||||
Pole Mount | ||||||
Wireless Uplink |
Ubiquiti Extended Warranty
Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.
In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.
On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.
Available warranty options:
Highlights:
High Density Tests conducted on Access Points where done in a high density environment with 100 WiFi clients running the test concurrently
Average Throughput
Uplink (100 Clients)
HD Video Streaming
Average Multicast Pass
Percentage(100 Clients)
Average 5Mb FTP upload
Time (100 Clients)
The UniFi WiFi AP delivers unprecedented wireless awareness and security, including tools for real-time spectrum monitoring, airtime utilisation analytics, and intrusion detection/prevention. Using a persistent spectral scan, the AP constantly monitors the RF environment to check for both potential malicious activity and the best channel for network performance.
UniFi is the premiere Software Defined Networking (SDN) solution with seamless integration of high-performance switching, gateways, and more.
