These transport racks meet all EIA standards and are compatible with all the major OEMs such as Dell, HP, IBM and Cisco. The 24" (610 mm) deep transport rack is for installations that require a shallow depth such as audio and video equipment. The transport racks are available in 6U & 8U heights. The transport racks are completely shock isolated. These hard cases are warranted for life to the original owner.
Technical Specifications -
Rack Units |
6U or 8U |
Rack Mount Depth |
24" (609.6 mm) |
Weight Capacity |
8U: 400 lbs (181.4 kgs) |
Rack Outside Dimensions |
H x W x D (without casters) |
Hole Type |
EIA 3/8" square holes |
Cable Management |
Multiple wire tie points |
Rack Post Shape |
L-Shaped rack posts |
Rack Ventilation |
Front and rear doors must be removed for proper ventilation |
Rack Doors |
Doors are removable. No tools required |
Rack Casters |
Heavy Duty Casters are sold separately |
Rack Construction |
Internal aluminium and steel frame - external roto-molded plastic |
Assembly Notes |
Ships fully assembled |
Specifications | |
Rack Units | 6U or 8U |
Rack Mount Depth | 24" (609.6 mm) 29" (737 mm) |
Weight Capacity | 8U: 400 lbs (181.4 kgs) 6U: 300 lbs (136 kgs) |
Rack Outside Dimensions H x W x D (without casters) |
8U, 29": 26.0 x 26.0 x 41.5" (660 x 660 x 1054 mm) 6U, 29": 18.5 x 26.0 x 41.5" (470 x 660 x 1054 mm) 8U, 24": 26.0 x 26.0 x 36.0" (660 x 660 x 914 mm) 6U, 24": 18.5 x 26.0 x 36.0" (470 x 660 x 914 mm) |
Hole Type | EIA 3/8" square holes |
Cable Management | Multiple wire tie points |
Rack Post Shape | L-Shaped rack posts |
Rack Ventilation | Front and rear doors must be removed for proper ventilation |
Rack Doors | Doors are removable. No tools required |
Rack Casters | Heavy Duty Casters are sold separately Casters are a tool-less design, lockable and removable Casters add 4.5" to height (114.3 mm) |
Rack Construction | Internal aluminium and steel frame - external roto-molded plastic |
Assembly Notes | Ships fully assembled |
