Molex Antimicrobial Module Contura FTP 568A B C6A, White

The PowerCat 6A shielded Contura Module features the unique DataGate shielded connector. This shielded connector offers superior alien crosstalk suppression, excellent insertion loss, and provides enhanced electromagnetic interference (EMI) protection by utilizing robust die-cast zinc alloy connector body housing. This shielded connector also features a unique spring loaded shutter that not only protects it from dust and contaminates, but the ingenious spring loaded design also ejects improperly seated patch cords. The shielded connector is dual color coded for either 568A or 568B wiring schedules. The DataGate PowerCat 6A shielded connector is also backwards compatible with shielded C6 and C5e systems.

Molex Connected Enterprise Solutions modular wall outlet range Contura was designed to combine aesthetics with functionality and to support a growing requirement for shielded cabling systems. The contemporary design of the products is ideal for the modern office and provides the user with the flexibility of installing as many modules as required. The product family consists of Single and Double Gang Wall Plates with Grid Plate, a shuttered Shielded DataGate 6A Module and a Blank Module. The angled design of the module reduces patch cord bend radius and features a protected labelling feature. Individual ports may be color coded for site-specific network administration, by fitting connector icon labels.

Features & Advantages

• Contemporary design
• Angled design reduces the patch cord bend radius
• Protected labeling feature for clear port labeling
• Accommodates flexible cable routing by allowing 90° or 180° cable entry
• 360° shielded C6A DataGate Jack provides superior alien crosstalk suppression and enhanced electromagnetic interference (EMI) protection
• IDC V-shaped contacts designed to flex, not fatigue when terminated for reliable termination
• Molex DataGate Jacks may accommodate both solid (AWG 22 to AWG 24) and stranded (AWG 26) cables

Technical Information

Connector

• Housing: Zinc Alloy plated Bright Ni/Cu
• Operating Life: Min. 750 insertion cycles
• Contact Material: Copper Alloy
• Contact Plating: 50µ Gold/ 50µ Nickel minimum
• Contact Force: 100g minimum
• Plug Retention Force: 6.8kg minimum

IDC Connector

• Housing: Thermoplastic, UL94V-0 rated
• Operating Life: 20 re-terminations
• Contact Material: Copper Alloy
• IDC Contact Plating: Tin Matte Finish
• Contact Force: 100g minimum
• Wire Accommodation: 22-24 AWG solid, 26 AWG stranded

Electrical

• Interface Resistance: 20m?
• Initial Contact Resistance: 2.5m?
• Initial Contact Resistance: >100 M?

• Minimum Backbox Depth Requirement: 44mm (straight entry) 37mm (side entry)
• Termination Tool: 110
