Unite EAGLE-i Power Expansion Module

The Unite Technologies PDU Expansion unit extends the number of CL-Amps devices or intelligent power strips (often referred to as power distribution units; PDUs) that can be monitored by the Eagle-i SNMP monitoring unit.

The Eagle-i SNMP monitoring unit is capable of monitoring six single phase power trips or CL-Amp devices. Attaching the PDU Expansion unit to the Eagle-i increases the maximum number of PDUs that can be monitored from a single IP address to 24.

The PDU-Expansion unit supports 18 single phase PDU units or CL-Amp devices or a combination of the two power monitoring devices to a maximum of eighteen devices.

The PDU Expansion unit has a 1U form factor, and connects directly to either one of the two Eagle-i expansion ports. (It does NOT require its own network connection.) The Eagle-i will support one PDU-Expansion.

• 1 U Mounting form factor.
• 18 PDU Expansion ports supporting;
• Unite Technologies CL-Amp current monitoring devices.
• Unite Technologies RS485 Single Phase Power Distribution Units (PDUs)
• Unite Technologies PDUs “Monitor Only” with RJ45 serial connectors. (The PDU must be set for RS485
  operation.)
• Unite Technologies PDUs Monitor and Control with or without per outlet monitoring RJ45 serial connector.
  (The PDU must be set for RS485 operation.)
• Simple connection to Eagle-i host unit using standard RJ45 patch cable (maximum length 30Metres).
• No Address or configuration information is required for PDU Expansion Unit.
• Two independent input mains power supplies for power redundancy – will work from single feed.
• PDU Expansion ports are labelled ‘7’…’24’, with a status indicator for each port.
• Dimensions: 483mm x 108mm x 44mm
• Weight: 1.62Kg
• Power: 110VAC ~ 230VAC, 40W Max.
• Europe Compliance: CE 2009, EN60950, EN55022, EN55024
