HP E3500-48G-PoE+ yl Switch
J9311A
Price:
FEJ9311A
Part No:
No Stock: 1 - 2 Weeks
Delivery:
unit(s)
Overview
Details
The HP ProCurve Switch 3500 Series consists of the most advanced intelligent edge switches in the HP ProCurve Networking product line. The 3500 series includes 24-port and 48-port stackables. The foundation for all these switches is a purpose-built, programmable ProVision ASIC that allows the most demanding networking features, such as Quality of Service (QoS) and security, to be implemented in a scalable yet granular fashion. With a variety of Gigabit and 10/100 interfaces, integrated PoE and Non-PoE options,10-GbE capability on Gigabit switches, the 3500 switches offer excellent investment protection, flexibility, and scalability, as well as ease of deployment, operation, and maintenance.
Features:
Features:
- Virtual Router Redundancy Protocol (requires Premium License): VRRP allows groups of two routers to dynamically back each other up to create highly available routed environments
- Pre-standard PoE support: detects and provides power to pre-standard PoE devices; see list of supported devices in the product FAQ at www.ProCurve.com
- IEEE 802.3ad Link Aggregation Control Protocol (LACP) and ProCurve trunking: support up to 60 trunks, each with up to 8 links (ports) per trunk
- ProCurve switch meshing: dynamically load-balances across multiple active redundant links to increase available aggregate bandwidth
- IEEE 802.1AB Link Layer Discovery Protocol (LLDP): automated device discovery protocol for easy mapping by network management applications
- UDP helper function: UDP broadcasts can be directed across router interfaces to specific IP unicast or subnet broadcast addresses and prevent server spoofing for UDP services such as DHCP
- Loopback interface address : defines an address in RIP and OSPF that can always be reachable, improving diagnostic capability
- GARP VLAN Registration Protocol: allows automatic learning and dynamic assignment of VLANs
- High-speed/capacity architecture: up to 153.6 Gbps crossbar switching fabric provides intra- and inter- module switching with up to 111.5 million pps throughput on the purpose-built ProVision ASICs
- Uni-Directional Link Detection (UDLD): monitors cable between two switches and shuts down the ports on both ends if the cable is broken turning the bi-directional link into uni-directional; this prevents network problems such as loops
- Selectable queue configurations: increase performance by selecting the number of queues and associated memory buffering that best meet the requirements of your network applications
- Management simplicity: ProCurve-common networking features and CLI implementation (common across ProCurve 8200zl/6600/6200yl/5400zl/3500 switches)
- Jumbo frames: on Gigabit and 10-Gigabit ports, allow high-performance remote backup and disaster-recovery services
- IEEE 802.1s Multiple Spanning Tree Protocol: provides high link availability in multiple VLAN environments by allowing multiple spanning trees; encompasses IEEE 802.1D Spanning Tree Protocol and IEEE 802.1w Rapid Spanning Tree Protocol
- RMON, XRMON, and sFlow v5: provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events
- IEEE 802.3af Power over Ethernet: provides up to 15.4 W per port to IEEE 802.3af compliant PoE powered devices such as IP phones, wireless access points, and security cameras
- Remote Intelligent Mirroring: mirrors selected ingress/egress traffic based on ACL, port, MAC address, or VLAN to a local or remote 8200zl/6200yl/5400zl/3500yl switch anywhere on the network
- VLAN support and tagging: supports the IEEE 802.1Q standard and 2,048 VLANs simultaneously
- Auto-MDIX: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports
- Sparing simplicity: ProCurve zl-common accessories (interface modules, power supplies)
- Static IP routing: provides manually configured routing; includes ECMP capability
- RIP: provides RIPv1 and RIPv2 routing
- OSPF (requires Premium License): includes host-based ECMP to provide link redundancy/scalable bandwidth and NSSA
- IEEE 802.1ad Q-in-Q (requires Premium License): increases the scalability of Ethernet network by providing a hierarchical structure; connects multiple LAN's on high-speed campus or metro network
- IPv6: IPv6 host: the switches can be managed and deployed at the edge of IPv6 networks; Dual stack (IPv4/IPv6): provides transition mechanism from IPv4 to IPv6; supports connectivity for both protocols; MLD snooping: forwards IPv6 multicast traffic to the appropriate interface; prevents IPv6 multicast traffic from flooding the network; IPv6 ACL/QoS: supports ACL and QoS for IPv6 network traffic; IPv6 ready: the switch hardware can support IPv6 routing, tunneling, and security
- IEEE 802.1v protocol VLANs: isolate select non-IPv4 protocols automatically into their own VLANs
- Server-to-switch distributed trunking: allows a server to connect to two switches with one logical trunk that consists of multiple physical connections; enables load-balancing and increases resiliency
