Clarity5e TracJack 45 Degree Module

Part No.:

OR-TJ5E45

Discontinued

This product is no longer available from Comms Express.

need assistance - call us on 0845 2000 256

Twitter/Facebook

Related Products

18u 600 (w) x 800 (d) Prism Data Cabinet/Data Rack

Available in Grey & Black

£272.00

£326.40 Inc VAT.

24 Way RJ45 Cat5e Through Coupler Patch Panel - 1u

£35.00

£42.00 Inc VAT.

48 Way RJ45 Cat5e UTP Patch Panel - 2u

(Available in Black, Red, Green, Blue & Beige)

£60.00

£72.00 Inc VAT.

48u 800mm x 1000mm Value Server Cabinet/Rack

Uspace Server Rack In Black

£597.00

£716.40 Inc VAT.

27u Prism PI 800 (w) x 1000 (d) Server Cabinet/Rack

£413.00

£495.60 Inc VAT.

LC - LC Multimode Duplex Fibre Patch Leads

62.5/125 (OM1), 50/125 (OM2) & 50/125 (OM3)

£6.55

£7.86 Inc VAT.

Cat6 UTP 4 Pair Cable (LSOH) 305mtr boxes

Cat6 UTP 4 Pair Cable - 305mt Box

Available Grey (PVC) or Purple & Orange (LSOH)

£75.45

£90.54 Inc VAT.

Netgear GS748T

48 Port Gigabit Smart Switch + 4x Fibre Module Slots

£339.99

£407.99 Inc VAT.

24u 600mm x 1000mm Value Server Cabinet/Rack

Uspace Server Rack In Black

£405.00

£486.00 Inc VAT.

42u Prism PI 600 (w) x 1000 (d) Server Rack/Cabinet

£429.00

£514.80 Inc VAT.

Overview

Clarity5E Angled TracJack, ETL verified to TIA Category 5e component specification, is front-loading and front removable. New universal T568A/B wiring label and tapered wiring towers simplify termination. Center tuned to Clarity5E patch cords for significant performance above Category 5e

SPECIFICATIONS
Category Performance/ Application	Category 5e/UTP
Footprint	TracJack
Wiring Scheme	T568 A/B
Color	Fog White
Number of Ports	1-port
Labeling & Identification	YES
Height	.92" (23.37 mm)
Width	.73" (18.54 mm)
Depth	1.23" (31.24 mm)
Wire Gauge	22-26 AWG
UL Listing No.	E131600
UL Standard	UL 1863
CUL Standard	UL 1863
CUL Listing No.	E131600
FCC Standard	Part 68
ETL Listing No.	3013270-003
ETL Standard, Tested To	TIA/EIA:568:B 2 Category 5e
Product Type or Accessory	Clarity^5E Angled Jack

CONSTRUCTION
	Material	Finish/Plating
Plastic TracJack Housing	High Impact Thermoplastic ABS/polycarbonate 94V-0
Array of eight modular dual reactance contacts	Beryllium Copper	Nickel plating and a minimum of 50 micro inches of selective gold plating in contact area
IDC contacts (Low noise)	Phosphor bronze	Nickel plating with tin over plate
Printed circuit board	Two-sided FR-4 epoxy resin/glass base with solder mask

FEATURES	BENEFITS
Angled design	Reduces profile of cord connection
ETL Verified to Category 5e component standard	Ensures standards compliance
Center tuned design	Transparent interface with Clarity^5E cords
Easy lace IDC housing	Reduces wiring time
Easy to follow universal wiring label	Quick, user-friendly, eliminates confusion
Front removable	Less intrusive access for adds, moves, changes
Standard TracJack footprint	Fits in all TracJack faceplates
Icon compatible, with 5E Marking on jack face	Supports 606 designation requirements
RoHS compliant	Lead free

SPECIFICATIONS

Category Performance/ Application

Category 5e/UTP

Footprint

TracJack

Wiring Scheme

T568 A/B

Color

Fog White

Number of Ports

1-port

Labeling & Identification

YES

Height

.92" (23.37 mm)

Width

.73" (18.54 mm)

Depth

1.23" (31.24 mm)

Wire Gauge

22-26 AWG

UL Listing No.

E131600

UL Standard

UL 1863

CUL Standard

UL 1863

CUL Listing No.

E131600

FCC Standard

Part 68

ETL Listing No.

3013270-003

ETL Standard, Tested To

TIA/EIA:568:B 2 Category 5e

Product Type or Accessory

Clarity^5E Angled Jack

CONSTRUCTION

Material

Finish/Plating

Plastic TracJack Housing

High Impact Thermoplastic ABS/polycarbonate 94V-0

Array of eight modular dual reactance contacts

Beryllium Copper

Nickel plating and a minimum of 50 micro inches of selective gold plating in contact area

IDC contacts (Low noise)

Phosphor bronze

Nickel plating with tin over plate

Printed circuit board

Two-sided FR-4 epoxy resin/glass base with solder mask

FEATURES	BENEFITS
Angled design	Reduces profile of cord connection
ETL Verified to Category 5e component standard	Ensures standards compliance
Center tuned design	Transparent interface with Clarity^5E cords
Easy lace IDC housing	Reduces wiring time
Easy to follow universal wiring label	Quick, user-friendly, eliminates confusion
Front removable	Less intrusive access for adds, moves, changes
Standard TracJack footprint	Fits in all TracJack faceplates
Icon compatible, with 5E Marking on jack face	Supports 606 designation requirements
RoHS compliant	Lead free
